- TPMS Valve 19 is a clamp-in tire pressure monitoring system (TPMS) valve stem for aluminum alloy wheels. It is a reliable replacement for OEM and aftermarket TPMS sensor systems.
-
This valve ensures:
- Airtight sealing
- Accurate tire pressure monitoring
- Long-term durability under various driving conditions
It is widely used in automotive repair shops, tire service centers, and by wholesale TPMS distributors.
Technical Specifications
TPMS Valve 19 is a clamp-in valve stem designed for tire pressure monitoring systems. It connects the TPMS sensor to the wheel rim and ensures airtight sealing while transmitting accurate tire pressure data to the vehicle monitoring system.
It is compatible with modern cars, SUVs, and light trucks equipped with electronic TPMS sensors.
- Model Number: TPMS-19
- Material: Brass, copper,rubber
- Model No.: TPMS-19
- Suitable: car
- Packaging Details：100 pcs in one plastic bag
- Delivery Time ：15 work days
Key Features
- High-strength aluminum alloy construction
- EPDM rubber sealing for reliable air-tight performance
- Built-in copper valve core for stable operation
- Corrosion-resistant and heat-resistant design
- Standard 11.3mm rim hole compatibility
- Compatible with OEM TPMS sensors
- Stable at high-speed driving
- Long service life with low maintenance
Application Range
TPMS Valve 19 is suitable for:
- Passenger cars
- SUVs and crossovers
- Light commercial trucks
- OEM TPMS systems
- Aluminum alloy wheel assemblies
Installation Guide
Step 1: Remove old valve stem
Carefully remove the damaged or worn TPMS valve from the wheel rim.
Step 2: Clean rim hole
Ensure the rim hole is clean and 11.3mm standard size.
Step 3: Install TPMS Valve 19
Insert the valve stem into the rim and align with TPMS sensor position.
Step 4: Tighten mounting nut
Secure the valve using correct torque tools.
Step 5: Inflate and test
Check for air leakage and ensure TPMS sensor signal is stable.
FAQ
Q1: What is TPMS Valve 19 used for?
A: Supports tire pressure monitoring sensors and ensures airtight sealing in aluminum wheels.
Q2: Is TPMS Valve 19 universal?
A: Fits most vehicles using 11.3mm clamp-in TPMS valve systems.
Q3: How long does it last?
A: Typically 3–5 years depending on driving and maintenance.
Q4: Does it include the sensor?
A: No, TPMS Valve 19 is only the valve stem.
Q5: Can it replace rubber valve stems?
A: Only in TPMS systems; not a replacement for standard rubber valves.
Get a Bulk Quote / Inquiry:
If you are looking for a reliable supplier or need a custom wholesale price, contact our sales representative instantly via WhatsApp or Email.
