TR 510 Tubeless Truck Tire Valve: Heavy-Duty Snap-in Rubber Valves for Commercial Vehicles

Product Details

Product Overview: > The TR 510 is a premium tubeless snap-in valve designed specifically for heavy-duty truck and trailer wheels. Featuring a high-temperature resistant rubber base and a reinforced brass core, it ensures airtight integrity under high-pressure conditions (up to 100 PSI). Ideal for rims with a .625" (16mm) valve hole.

Specification	Details
Industry Number	TR 510
Application	Truck, Bus, Trailer
Rim Hole Diameter	.625" (16mm)
Effective Length	50mm (Approx. 2")
Max Inflation Pressure	100 PSI
Material	EPDM Rubber + Brass Core

High-Temperature Resistance:

Crafted with EPDM rubber to withstand extreme road heat and prevent premature aging.

Superior Airtight Seal:

The precision-engineered brass valve core prevents air leakage during long-haul transport.

Standard Compliance:

Fully meets TMC (Technology & Maintenance Council) and ISO quality standards for commercial trucking.

FAQ about TR 510 Tire Valve

Q: What rim hole size does the TR 510 valve fit?
- A: The TR 510 is designed for standard large-bore rim holes of .625 inches (16mm), common in heavy truck wheels.
Q: Can TR 510 be used for high-pressure tires?
- A: Yes, it is rated for cold inflation pressures up to 100 PSI, making it suitable for most commercial truck applications.
Q: What is the difference between TR 510 and TR 415?
- A: While both fit .625" holes, the TR 510 is longer (50mm) and built with a more rugged construction for the heavy-duty demands of trucks, whereas the TR 415 is often shorter and used for lighter utility vehicles.
